Textile design and colour; elementary weaves and figured fabrics (1921)
Watson, William, F.T.I · London, New York [etc.] Longmans, Green and co. · leaf 24
with either weft or warppredominating, three different twills can be formed, each of which may be incUnedin either direction. Hence twills on four threads may be formed in six ways, asshown at E, F, G, H, I, and J in Fig. 9. The weaves E, F, and G on one side willhave H, 1, and J respectively on… … Kg. 8. 10 TEXTILE DESIGN AND COLOUB as, for instance, serge, blanket, sheeting, shalloon, and cassimere.The term swansdown is applied to the l-and-3 twill weave. On five threads six twill weaves, running to the right, may be woven, as shownat K to P in Fig. 9, while similar effects may be made…
