operation can also be performed with a machine, a representation of which is given in Figs. 15 and 16. The stringing machine (Fig. 15) is composed of a series of horizontal pegs A, which can be made to revolve by means of the lever and ratchet l and the cog-wheels K. A second series of horizontal… … Fig*. 16. — Details of Silk-stringing Machine. elbow — as loose pulleys, and also at right angles to this, by the revolution of the vertical spindle of the elbow. This last movement is caused as follows : Each spindle is supported by a collar on a box u, enclosing a toothed- wheel, which is…
