The textile industries : a practical guide to fibres, yarns & fabrics in every branch of textile manufacture, including preparation of fibres, spinning, doubling, designing, weaving, bleaching, printing, dyeing and finishing (1910)

Murphy, William S · London : The Gresham Publishing Company · leaf 142

An illustration from The textile industries : a practical guide to fibres, yarns & fabrics in every branch of textile manufacture, including preparation of fibres, spinning, doubling, designing, weaving, bleaching, printing, dyeing and finishing, 1910, leaf 142
ed fleece thus COMBING III delivered backwards is projected into the space between the last rowof needles and the plain segment whose front edge strokes the fleeceagainst and under the bottom roller, so as to present a clean surface tothe advancing nipper tuft for piecing. Meantime, the nipper… … Fig. 90.—Heilmann Cotton Comber. Section showing nipper bar and cushion plate in contact;comb cylinder commencing to comb the tuft of cotton and the top comb lifted. A, Lap, 10^ in., 11 in., or 12 in. wide. B, Wood lap rollers. c, Lap plate, d. Feed rollers. E, Nipper bars.F, Cushion plate. G, Comb…
