Fig. io8.—French Drawing Frame height of the porcupine roller has two advantages; it grips on tothe wool more closely than if the periphery were level with the nip,and offers to the wool a wider drawing surface. The sliver is drawnround the porcupine roller, but the pins are so disposed that they … Fig. 109.—Diagram of French Drawing FrameA, B, c, D, Fluted rollers; e, Porcupine; f, g, Leather bands having a slight transverse movement; h, Balling head do not hook into the fibres and let the front drawing rollers, whichare revolving in close proximity, take ready possession. Betweenthese parts…
