faller he fixed compound levers actuated byrotary cams (fig. 131), which, brought into action by the outward runof the carriage, lowered the wire level with the points of the spindles.For further action he made another lever, with a friction roller, whichtraversed an inclined plane called the… … Fig. 133.—Section showing Small Speed Drum A, A, Frame, b, b, Carriage, c, Guide pulleys, d, e, Double-grooved pulleys, f, Faller.G, Counter faller shaft. H, Drum, i, Balance lever, j. Ratchet wheel. To effect the variation in the speed and length of revolution ofthe spindles required by the…
