The textile industries : a practical guide to fibres, yarns & fabrics in every branch of textile manufacture, including preparation of fibres, spinning, doubling, designing, weaving, bleaching, printing, dyeing and finishing (1910)
Murphy, William S · London : The Gresham Publishing Company · leaf 191
Fig. 241. -Lappet Disc. The dotted line in the groove shows the trackof the point of the pick at each stroke. Vol. IV. 87 146 WEAVING … Fig. 242.—Swivel Shuttle (fig. 241). First, with a comb, the maker drew concentric circles onthe surface of the wooden disc, the spaces between the lines beingproportioned to the spaces between the dents in the reed. From thecentre of the wheel radial lines were drawn to divide the wheel intoequal…
