Fig. 244.—Swivel Shuttle MotionA, Rack, sliding by means of the lever B. c, Pinions driven by the rack and driving the shuttles. While the plain cloth is being woven, the swivel shuttles are heldup out of gear; but at the point where figuring begins the frame islowered, and it places the shuttles…
