Valve setting: simple methods of setting the plain slide valve. Meyer cut-off. Corliss. and poppet types (1908)

Collins, Hubert Edwin, 1872- · New York [etc.] Hill publishing company · leaf 53

An illustration from Valve setting: simple methods of setting the plain slide valve. Meyer cut-off. Corliss. and poppet types, 1908, leaf 53 — FIG. 42. FIG. 43. travel at least as fast as the main valve from the position shown in Fig.40 to that shown in Fig. 41. Now comes the question of length of the eccentric rod. Assuming thatin all the cases spoken of in this article an engine of 20-in, stroke wereused, it will be found that in the…

Steam-engines

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
