The textile industries : a practical guide to fibres, yarns & fabrics in every branch of textile manufacture, including preparation of fibres, spinning, doubling, designing, weaving, bleaching, printing, dyeing and finishing (1910)
Murphy, William S · London : The Gresham Publishing Company · leaf 195
rods, s, Temple. T, Breast beam, u, Cloth beam. Ol Iieavy tabriCS. A. short stout shaft isplaced at right angles to the crank, the connection being made witha pair of bevel wheels, one of which is a change wheel. Indirectdriving gear consists of a pulley on the end of the short shaft, a bevelchange… … Fig. 349-- -Diagram of Loom, showing Going Part and Tappet Motion THE GOING PART 165 of driving gives unity to the whole working of the loom, and facilitatesalterations in speeds through the change wheel, thus obviating the 012 3 4 5 6 7 8 9 lOII 12 H—
Textile industry · Textile fabrics
Internet Archive · UMass Dartmouth, Claire T. Carney Library · Public Domain Mark 1.0. Free to use for anything.
