The textile industries : a practical guide to fibres, yarns & fabrics in every branch of textile manufacture, including preparation of fibres, spinning, doubling, designing, weaving, bleaching, printing, dyeing and finishing (1910)
Murphy, William S · London : The Gresham Publishing Company · leaf 96
. The rows ofhooks are scarcelyI in. apart, and thecontiguous rows arecoupled by two neckcords joined about9 in. below thebottom board. An-other feature of noteis the needles (fig. 292), each one of which grips into two hooks Like many of the newerJacquards, the cylinder of =^=^^ this machine is… … Fig. 291.—Crossleys Jacquard A, B, Griffe frames. c, Grid. d, Needles.needles. f, Catch driving cylinder e forward,back by hand. k, Neck cords. E, Cylinder actuatingH, Catch for pulling E ^ VOL. V. IGO 74 WEAVING the points of the needles. On the vertical lever, passing up the otherside of the…
Textile industry · Textile fabrics
Internet Archive · UMass Dartmouth, Claire T. Carney Library · Public Domain Mark 1.0. Free to use for anything.
