Taggart, William Scott · London : George Routledge & Sons, Ltd. · leaf 56
Rf. 54. j|.55. of metal B cut out in the form of a heart and fixed on a shaftA. A stud C is kept in contact with the periphery of thecam, so that as the earn revolves the pin C will rise and fallbetween the smallest and largest diameter of the cam. Itwill readily be seen that the shape of the cam…
Textile machinery
Internet Archive · UMass Dartmouth, Claire T. Carney Library · Public Domain Mark 1.0. Free to use for anything.
