Taggart, William Scott · London : George Routledge & Sons, Ltd. · leaf 80
,and the whole process is termed resolving a resultant into itsrectangular components. Example.—Resolve the force SF of 30 lb. into its rectangular com-ponents {see Fig. 93). Draw SF to scale = 3o lb. From S drawa vertical line SA, and from F draw a horizontal line FA. Thevertical and horizontal… … Fi«j.95. fT<^.94
Textile machinery
