Textile raw materials and their conversion into yarns : (the study of the raw materials and the technology of the spinning process) a text-book for textile, trade and higher technical schools, as also for self-instruction ; based upon the ordinary syllabus and curriculum of the Imperial and Royal Austrian weaving schools (1901)

Zipser, Julius, Salter, Charles · London : Scott, Greenwood · leaf 211

An illustration from Textile raw materials and their conversion into yarns : (the study of the raw materials and the technology of the spinning process) a text-book for textile, trade and higher technical schools, as also for self-instruction ; based upon the ordinary syllabus and curriculum of the Imperial and Royal Austrian weaving schools, 1901, leaf 211
g. 123) consists of the worm, />, mounted on thereel shaft, 0, and engaging in the 80-tooth worm wheel, q,which is advanced by one tooth, in the direction indicatedby the arrow, at each turn of the reel. Consequently, aftereighty turns of the reel, the worm wheel will have made onecomplete… … Fig. 123.—Counting Mechanism on the Cotton Reel (front view). rail, k, which is drawn back by the spring, 11, each time theraising of s enables this to be done, i.e., after each eightiethturn of the reel, or six times during the winding of a hank. TEXTILE RAW MATERIALS. 205 A highly original and…

Textile fibers · Spinning

Internet Archive · UMass Dartmouth, Claire T. Carney Library · Public Domain Mark 1.0. Free to use for anything.
