Textile raw materials and their conversion into yarns : (the study of the raw materials and the technology of the spinning process) a text-book for textile, trade and higher technical schools, as also for self-instruction ; based upon the ordinary syllabus and curriculum of the Imperial and Royal Austrian weaving schools (1901)

Zipser, Julius, Salter, Charles · London : Scott, Greenwood · leaf 257

An illustration from Textile raw materials and their conversion into yarns : (the study of the raw materials and the technology of the spinning process) a text-book for textile, trade and higher technical schools, as also for self-instruction ; based upon the ordinary syllabus and curriculum of the Imperial and Royal Austrian weaving schools, 1901, leaf 257
o equal lengths is shown as a side view in Fig. 250 TEXTILE RAW MATERIALS. 142. At one end of the delivery roller shaft,/), is mounted aworm, r, which transmits the motion of p at a. reduced speedto the small worm wheel, t, this in turn actuating the worm, u^and wheel, v, which is provided with a… … Fig. 142.—Counting Mechanism in Flax Gill Box (side view). ment of the counting wheel causes the stud to release thenose, X. The length of sliver delivered up to this moment isequal to the peripheral measurement of the lower delivery-roller, p, multiplied by the number of teeth on t, the…

Textile fibers · Spinning

Internet Archive · UMass Dartmouth, Claire T. Carney Library · Public Domain Mark 1.0. Free to use for anything.
