Textile raw materials and their conversion into yarns : (the study of the raw materials and the technology of the spinning process) a text-book for textile, trade and higher technical schools, as also for self-instruction ; based upon the ordinary syllabus and curriculum of the Imperial and Royal Austrian weaving schools (1901)

Zipser, Julius, Salter, Charles · London : Scott, Greenwood · leaf 317

An illustration from Textile raw materials and their conversion into yarns : (the study of the raw materials and the technology of the spinning process) a text-book for textile, trade and higher technical schools, as also for self-instruction ; based upon the ordinary syllabus and curriculum of the Imperial and Royal Austrian weaving schools, 1901, leaf 317
or the hand cranks have been released. The whole machineis firmly bolted on to the foundation by screw-bolts, t. 3IO TEXTILE RAW MATERIALS. The newer form of hydro-extractor is illustrated by thevertical section given in Fig. 192, wherein the correspondingparts are lettered the same as Figs. 190… … Fig. 192.—Hydro-extractor with Overhead Friction Driving Gear, new form(vertical section). of the top frame,/, and the substitution of a setting screw, r,for the flat spring producing friction between the two cones.The belt is thrown from the fast pulley, k^, to the loose pulley, TKXTILE RAW…
