Textile raw materials and their conversion into yarns : (the study of the raw materials and the technology of the spinning process) a text-book for textile, trade and higher technical schools, as also for self-instruction ; based upon the ordinary syllabus and curriculum of the Imperial and Royal Austrian weaving schools (1901)
Zipser, Julius, Salter, Charles · London : Scott, Greenwood · leaf 318
he flat spring producing friction between the two cones.The belt is thrown from the fast pulley, k^, to the loose pulley, TKXTILE RAW MATKRIALS. 3II k, and vice versa by the belt fork, a, which is moved by thehand wheel, x, and its attached rack and pinion gear. Theinaccessible footstep bearing, d,… … Fig. 193.—Hydro-extractor with Belt-driving Gear (vertical section). A belt-driven machine is shown in Fig. 193. The verticalshaft, a, carries, between the footstep and collar bearings, abroad driving pulley, driven either by a twisted belt from ashafting, or by a straight belt direct from the…
Textile fibers · Spinning
Internet Archive · UMass Dartmouth, Claire T. Carney Library · Public Domain Mark 1.0. Free to use for anything.
