ouble Cleaner, with Swinging Rollers. ^^amm^m. rail, ^if, to the bobbin, h. The oscillating movement of theframe, c, is effected by the crank disc, ;/, which is driven by abelt, q, from the pulley, 0, on the main shaft, and actuates thelinked rods, / and k, the latter being guided by the frames,… … Fig. 300.—Double Gauging Machine for Chappe Silk Yarns (vertical section). may be either a separate appliance, such as is used for woollenyarns, or fitted as an attachment to the cleaning machine. Acombination of this kind is shown in Fig. 298, the right-handside of the machine being fitted with a…
