Theoretical estimation of the internal speed variation of a 3500 horse-power vertical cross-compound engine (1904)
Abbott, William Lamont, 1861-1951 · leaf 14
Cr c 5.5 DE IT WAT ION Or CURVE OF INERTIASCALE 5 UBS. = I … Referring to Fig.l, draw line MP, representing in ex-tent the combined length of the connecting rod and the piston tra-vel. From the point 0 with radius OP strike a circle representingthe crank travel. From the other end of the line MP lay off thedistance KM*, representing the piston travel. low,…
