point. In Fig. 43, neither of the three points is at the intersectionof two of the sides of the parallelogram, and hence there is a ADJUSTMENT, USE, AND CARE OF INSTRUMENTS. 165 fourth point unused, having the same properties as the fixed,tracing, and copying points, it being at the intersection of… … Fig. 43. combinations which will do the work of a pantograph. Theonly essential conditions are that the fixed, the tracing, and thecopying points shall lie in a straight line on at least three sidesof a jointed parallelogram, either point serving any one of thethree purposes. i-5?>* Use of the…
