^ mw\ niter- Fig. 63. the next half cycle current flows only through DB, charging Bnegatively with respect to 0. The potential difference betweenA and B (if the condensers did not discharge themselves) wouldtherefore be twice the transfonner voltage. What actuallyhappens is that the one condenser… … Fig. 64. represents the potential of the point D with respect to 0, the curvesAA and BB will represent the potentials of A and B respect-ively with regard to 0. The potential difference between A and B istherefore obtained by adding the curves A and B and is given byEE. Thus, although the…
