Thermodynamics of the steam-engine and other heat-engines (1907)
Peabody, Cecil H. (Cecil Hobart), 1855-1934 · New York, J. Wiley & sons; [etc., etc.] · leaf 308
-Engine. An ideal sketch isgiven by-Fig. 63. £ is a displacer piston filledwith non-conducting material, and workingfreely in an inner cylinder. Between thiscylinder and an outer one from A to C isplaced a regenerator made of plates of metal,wire screens, or other material, so arrangedthat it will… … Fig. 63. 300 INTERNAL-COMBUSTION ENGINES inner is pierced with holes through which the air streams whendisplaced by the plunger. At the upper end there is a coil ofpipe through which cold water flows. The working cylinder Hhas free communication with the upper end of the displacercylinder, and…
Thermodynamics · Steam-engines · Heat-engines
