Thermodynamics of the steam-engine and other heat-engines (1907)
Peabody, Cecil H. (Cecil Hobart), 1855-1934 · New York, J. Wiley & sons; [etc., etc.] · leaf 509
there are to be 36 stages. If the methodof the table on page 497 were applied to a turbine having thefull 36 stages now contemp ated, it would have 37 lines; namely,the ten already set down, and three intermediate entries betweeneach pair of consecutive lines; but the temperatures found inthat… … Fig. III. which will suffice for illustration. Beginning with the lowest stage the area to be supplied will be 2.25 X 158 -^ 600 = 0.592 square feet; where 600 is the velocity of the jet computed on page 495. The circumference of a circle having the diameter of 4.14 feet is 13 feet; but of this a…
Thermodynamics · Steam-engines · Heat-engines
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
