Finch, James Kip, 1883- · New York : John Wiley & Sons, Inc. · leaf 151
r they are away. Now note the deline-ations shown above for fences, roads, etc., and how this sameperspective effect is secured. Another feature in perspective is shown in Fig. 73. Imaginea circular driveway or track. The perspective appears widerin the foreground ah than at the back cd as shown in… … J THE SKETCHING SCREEN 131 full width. Applying these same principles to the case of awinding stream we understand how the stream shown in Fig.72 is drawn. Fig. 74 shows a landscape sketch and illustrateshow various delineations are combined to produce a cleardrawing when due allowance is made for…
Cartography · Military maps
