A treatise on ship-building and navigation. In three parts, wherein the theory, practice, and application of all the necessary instruments are perspicuously handled. With the construction and use of a new invented shipwright's sector ... Also tables of the sun's declination, of meridional parts ... To which is added by way of appendix, an English abridgment of another treatise on naval architecture, lately published at Paris by M. Duhamel .. (1754)

Murray, Mungo, d. 1770, Duhamel du Monceau, M., 1700-1782. Treatise on ship-building · London, Printed for D. Henry and R. Cave, for the author · leaf 204

An illustration from A treatise on ship-building and navigation. In three parts, wherein the theory, practice, and application of all the necessary instruments are perspicuously handled. With the construction and use of a new invented shipwright's sector ... Also tables of the sun's declination, of meridional parts ... To which is added by way of appendix, an English abridgment of another treatise on naval architecture, lately published at Paris by M. Duhamel .., 1754, leaf 204 — w perpendiculars betwixt each on the floor plane. We mightthen indeed find points in the diagonal, betwixt the timbers formed,which would give the beveUings of each floor timber with its corref-ponding futtock. S E C T. II. To find the Bevellings of the lranfo?ns. (Plate 7.) I^Here are two ways of…

Shipbuilding · Navigation

Internet Archive · Public Domain Mark 1.0. Free to use for anything.
