A treatise, giving a thorough description of the properties and supply of the fibres, as well as the various processes required for converting wool, cotton, silk from fibre to finished goods, covering both woven and knit goods ... construction of the most modern improvements to preparatory machinery ... accessories relating to construction and equipment of modern textile manufacturing plants .. (1895)

Posselt, E. A. (Emanuel Anthony), 1858-1921 · Philadelphia, E.A. Posselt; London, Sampson Low, Marston & Co · leaf 211

An illustration from A treatise, giving a thorough description of the properties and supply of the fibres, as well as the various processes required for converting wool, cotton, silk from fibre to finished goods, covering both woven and knit goods ... construction of the most modern improvements to preparatory machinery ... accessories relating to construction and equipment of modern textile manufacturing plants .., 1895, leaf 211
border, the measuring chain 7 is used inconnection with the pattern chain. The measuringchain is always working and when it is desired to makea large stripe a special link with a side projection isput in the pattern chain 2, which, when it comesaround, presses the pawl 5 out of contact with… … the arm 13 off of the pin 12 and allows the spring 11to pull the pawl 6 into contact with the ratchet 4which starts the latter, thus taking the projection onthe chain from under the pawl 5 and allowing it toagain engage the ratchet 4. The pawl 6 is thrown outof contact as soon as the link on the…

Textile fabrics · Textile industry · Textile machinery
