A treatise, giving a thorough description of the properties and supply of the fibres, as well as the various processes required for converting wool, cotton, silk from fibre to finished goods, covering both woven and knit goods ... construction of the most modern improvements to preparatory machinery ... accessories relating to construction and equipment of modern textile manufacturing plants .. (1895)

Posselt, E. A. (Emanuel Anthony), 1858-1921 · Philadelphia, E.A. Posselt; London, Sampson Low, Marston & Co · leaf 308

An illustration from A treatise, giving a thorough description of the properties and supply of the fibres, as well as the various processes required for converting wool, cotton, silk from fibre to finished goods, covering both woven and knit goods ... construction of the most modern improvements to preparatory machinery ... accessories relating to construction and equipment of modern textile manufacturing plants .., 1895, leaf 308
ts 1. The inner end of the lever 4 is supportedin a loop 6, depending from the cross bar 2, of theframe, and upon the lever 4 is mounted the othersqueeze roller 7, which is in normal condition duringthe running of the machine, parallel to the lowersqueeze roller 3. The outer end of the lever 4… … outer end of arm 10, the inner end of which is piv-otally secured to bracket 11, projecting from the adja-cent standard 1 of the machine. Below the arm 10 a bracket arm 12 projects fromthe standard 1, and to the end of the arm 12 is ful-crumed a bell crank lever 13, the short arm of whichhas a…

Textile fabrics · Textile industry · Textile machinery
