A treatise, giving a thorough description of the properties and supply of the fibres, as well as the various processes required for converting wool, cotton, silk from fibre to finished goods, covering both woven and knit goods ... construction of the most modern improvements to preparatory machinery ... accessories relating to construction and equipment of modern textile manufacturing plants .. (1895)

Posselt, E. A. (Emanuel Anthony), 1858-1921 · Philadelphia, E.A. Posselt; London, Sampson Low, Marston & Co · leaf 378

An illustration from A treatise, giving a thorough description of the properties and supply of the fibres, as well as the various processes required for converting wool, cotton, silk from fibre to finished goods, covering both woven and knit goods ... construction of the most modern improvements to preparatory machinery ... accessories relating to construction and equipment of modern textile manufacturing plants .., 1895, leaf 378
D therevolver or shear cylinder mounted upon the carryingframe F, connected by a hinge to frame A by shaft E;H indicates the draft roll; I the brush; and a thevarious guide rollers for directing the cloth (repre-sented by the dot and dash line K) through the ma-chine in the direction indicated by… … Fig. 29. ing the revolver D, while its lower end is joined by apivot stud 4 to the rear arm of a rocker lever 6, that is 378 mounted on a shaft 7, supported in stationary loear-ings 8, fixed to the lower part of the frame A; saidshaft being movable in its bearings and extendingacross the frames…

Textile fabrics · Textile industry · Textile machinery
