A treatise, giving a thorough description of the properties and supply of the fibres, as well as the various processes required for converting wool, cotton, silk from fibre to finished goods, covering both woven and knit goods ... construction of the most modern improvements to preparatory machinery ... accessories relating to construction and equipment of modern textile manufacturing plants .. (1895)

Posselt, E. A. (Emanuel Anthony), 1858-1921 · Philadelphia, E.A. Posselt; London, Sampson Low, Marston & Co · leaf 388

An illustration from A treatise, giving a thorough description of the properties and supply of the fibres, as well as the various processes required for converting wool, cotton, silk from fibre to finished goods, covering both woven and knit goods ... construction of the most modern improvements to preparatory machinery ... accessories relating to construction and equipment of modern textile manufacturing plants .., 1895, leaf 388
I-shapedbeams 5 and 6, while the lower roller 1 is mountedin bearings or journals 7 and 8 in the downwardlyprojecting portions of the inverted U-shaped bridge9, which is adapted to slide vertically between thelegs 10. The bearings 7 and 8 of the lower roller 1 387 are raised or lowered by means of… … Fig. 2. by means of the worm 18 on the driving shaft19 the screw 14 is raised or lowered, and withit the bridge 9 and the bearings 7 and 8, accordingto the direction in which the worm gear wheel 13 isturned. The worm gear wheel 13 is provided at itslower end with a lock nut 17, which prevents it…
