A treatise, giving a thorough description of the properties and supply of the fibres, as well as the various processes required for converting wool, cotton, silk from fibre to finished goods, covering both woven and knit goods ... construction of the most modern improvements to preparatory machinery ... accessories relating to construction and equipment of modern textile manufacturing plants .. (1895)

Posselt, E. A. (Emanuel Anthony), 1858-1921 · Philadelphia, E.A. Posselt; London, Sampson Low, Marston & Co · leaf 57

An illustration from A treatise, giving a thorough description of the properties and supply of the fibres, as well as the various processes required for converting wool, cotton, silk from fibre to finished goods, covering both woven and knit goods ... construction of the most modern improvements to preparatory machinery ... accessories relating to construction and equipment of modern textile manufacturing plants .., 1895, leaf 57
e side frame of the ma-chine. During the lower half of the revolution ofthis crank, its pin acts simply to advance the harrow,but when the crank pin reaches the upper end ofslot 8. the harrow is carried upward, backward anddownward. This sudden contact of the crank pinwith the upper end of the slot… … movement, the forward ends of said tracks are up-turned as at 11 and 12; again, to assist the crank Gto more easily raise the harrow, the opposite endsof the tracks are upturned as at 13 and 14- Beneath the squeeze rollers 15 there is placed atank 16 to receive the scouring liquor, which…

Textile fabrics · Textile industry · Textile machinery
