A treatise, giving a thorough description of the properties and supply of the fibres, as well as the various processes required for converting wool, cotton, silk from fibre to finished goods, covering both woven and knit goods ... construction of the most modern improvements to preparatory machinery ... accessories relating to construction and equipment of modern textile manufacturing plants .. (1895)

Posselt, E. A. (Emanuel Anthony), 1858-1921 · Philadelphia, E.A. Posselt; London, Sampson Low, Marston & Co · leaf 76

An illustration from A treatise, giving a thorough description of the properties and supply of the fibres, as well as the various processes required for converting wool, cotton, silk from fibre to finished goods, covering both woven and knit goods ... construction of the most modern improvements to preparatory machinery ... accessories relating to construction and equipment of modern textile manufacturing plants .., 1895, leaf 76
is placed a frame for supportinga series of three pulleys (only two, 7 and 8, beingvisible in the illustration. Fig. 1, the third pulley 75 tieing placed on the other end of the machine), andalso spool spindles 9 and its spools 10. Each spindlecarries a pulley 11, resting on an endless cord 6,which… … pulley secured to a crank shaft 15, which is operatedby the treadles. A basin for water and for the silk cocoons is indi-cated at 16, being located directly over the hot cham-lier 17, which is provided with tubes IS (the samenumber as reels used in the machine—only one tubeteing shown) for…

Textile fabrics · Textile industry · Textile machinery

Internet Archive · Smithsonian Libraries · Public Domain Mark 1.0. Free to use for anything.
