Fig. 124. … Fig. 125. piers. Fig. 124 shows a pier bonded with 4-inch bondstones /;, the stepped-o£f brick fotmdations at r, and theconcrete base at (/. Fig. 125 shows a brick pier with 1-inch iron bonding platesat a, and the stepped-up brick foundation and concrete baseat c and //. BRICK NOGGIXG. 213. Stud…
