A treatise on architecture and building construction (1899)
International Correspondence Schools · Scranton, The Colliery engineer co. · leaf 242
Fig. 25. … 46 HEATING AND VENTILATION 17 flues, as shown at a. The bases of the tubes are set highenough above the floor to permit an abundant flow of airinto the flues at the bottom. Radiators constructed in thismanner are called flue radiatox^s. RADIATORS. CONSTRUCTION OF EADIATORS. 74. Radiators which are…
Architecture · Building
Internet Archive · New York Public Library · Public Domain Mark 1.0. Free to use for anything.
