A treatise on land-surveying; comprising the theory developed from five elementary principles; and the practice with the chain alone, the compass, the transit, the theodolite, the plane table, &c. Illustrated by four hundred engravings, and a magnetic chart (1875)
Gillespie, W. M. (William Mitchell), 1816-1868 · New York, D. Appleton · leaf 138
In Fig. 154, the hne of sight AB is represented as passing toone side of the centre, and the needle as pointing to 46°. In Fig.155, the compass is supposed to have been turned half around andthe other end of the sights to be directed to the same object.Suppose that the needle would have pointed to…
Surveying
Internet Archive · California Digital Library · Public Domain Mark 1.0. Free to use for anything.
