ject and that ofthe former, will be the angular distance of the objects in question.Thus, suppose the former bearing to be 40^ 30, and the latter10^ 15, both east, or both west,from the noHh or south, the anglewiU be 30^ 16. The divisions aregenerally numbered 5°, 10°, 15°,&c. around the circle… … CHAP II.] The Compass. 137 (233) The prismatic compass is generally held in the hand, thebearing being caught, as it were, in passing; but more accuratereadings would of course be obtained if it rested on a support, suchas a stake cut flat on its top. In the former mode, the needle never comes…
