d two squares were counted to theright, then 2 x 2.75 = 5| squares, should be counted upward, toE, and AE would be the required course. (272) With a paper protractori Engraved paper protractorsmay be obtained from the instrument-makers, and are very conve^ * This and all the following ratios may be… … nient. A circle of large size, divided into degrees and quartei-a,is engraved on copi^er, and impressions from it are taken on draw-ing paper. The divisions are not numbered. Draw a straight lineto represent a meridian, chrough the centre of the circle, in anyconvenient direction. Number the…
