A treatise on levelling, topography, and higher surveying (1876)
Gillespie, W. M. (William Mitchell), 1816-1868, Staley, Cady, b. 1840, ed · New York, D. Appleton and company · leaf 121
all scale,a small shaded rectangle rep-resents it. If colors are used,buildings of masonry are tinteda deep crimson (with lake), andthose of wood with Indian-ink.Their lower and right-hand sidesare drawn with heavier lines.Fences of stone or wood, andhedges, may be drawn in imita-tion of the… … Boat ferry, Rope ferry, Steam ferry, Ford for carriages, Ford for horses. Gold. Silver. Iron. Copper. Tin. Lead. Quicksilver. m E> 6 $ U ^ $ CONVENTIONAL SIGNS. 103 A large black circle, ©, may be used for Coal. Boundary-lines, of private properties, of townships, ofcounties,.and of States, may…Surveying
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
