s, which have been since intro-duced. Fig. 252 is a sectional elevation of the mill, the line ofsection being taken in a longitudinal direction, and exhibitingthe position of the stones, the engine, and driving gearing, andof such i^ortions of the subordinate apjiaratus as are visible onthe side of… … In these will be seen the driving gear, first motion wheels,and vertical shaft, by which motion is transmitted to the ma-chinery in the floors above. ]20 ON CORN MILLS. Fig. 253 is a plan of the bottom floor, showing engine andboilers, corresponding to the above, and taken on a horizontalline…
