Trompeter Patching and Switching Systems 1973 (1973)
Trompeter Electronics, Inc. · leaf 20
PNS AND PNSX The PNS or PNSX can be fabricated to provide paralleling for any number of jacks, receptacles, or special networks per customer specifications. Pictured units provide paralleling for four (4) jacks. Panel type or spacing of the connectors MUST be specified. Other types of connectors… … One input — 4— output Specify panel type or specify spacing. PN-2B-Z (50,75, 930) PN-2C => k 2.07 +| 2 jacks, one input —random paralleling. Same as PN-2A except can be used with high den- sity panels. PN-2A PN-2 1 jack, two input — fixed paralleling. 2 jacks, one input — fixed paralleling. Ree:…
