An illustration from Twentieth century hand-book for steam engineers and electricians with questions and answers; a practical non-technical treatise .., 1913, leaf 1104
ancebox so that all the resistance is in circuit. A rheostat con-sists of a number of resistances, Figs. 461 and 462, so ar-ranged that they can be cut in or out of the circuit with-out opening the circuit. By reference to Fig. 462, it willbe seen that the current enters at the handle, and… … Fig. 462 Eheostats for the shunt circuit of a dynamo should haveiSufficient resistance, so that when it is all inserted, theivoltage of the dynamo will slowly sink to zero. Thismethod of stopping the action of a dynamo is perfectlysafe, and should be followed wherever possible. We are now running…

Steam engineering · Electrical engineering · Steam turbines
