r, 6 feet. By reference to Fig. 244 it will be seen that the insideof the cylinder is stud.ded with rows of small stationaryblades, and that the rotor or revolving part of the ma-chine is also fitted with rows of small blades, similar inshape and dimensions to the stationary blades. WTien theupper… … Fig. 245 SECTION OF STANDARD WESTINGHOUSE SINGLE FLOW TURBINE 596 Steam Engineering understood by reference to Fig. 247^ which illustrates therelation of the stationary blades to the moving blades whenin position^ and also shows by the arrows the course of thesteam and its change of direction…
