LATHE. 193 LATHE, SMALL SELF-ACTING AND SCREW-CUTTING, by Charles Walton, Leeds, 1..,.Kg 2628 is a general side elevation of the lathe, and2624 is a plan corresponding. Fig. 2626 is an end elevation showing the geering. Fig. 2526 is a transverse section taken between the fast-head and the showing… … ■ ion f the ti> cone an I n ili latheH r when tl iction, and n Vol. ii. 18 194 LATHE. Fig. 2532 is a section through the driving-cone on the lathe-spindle. Fig. 2533 is a front view of the chuck. Fig. 2534 is a side elevation of the same; and Fig. 2535 a vertical section in the plane of the…
