Twentieth century hand-book for steam engineers and electricians with questions and answers; a practical non-technical treatise .. (1913)
Swingle, Calvin Franklin, 1846- [from old catalog] · Chicago, F. J. Drake & company · leaf 902
its deposition. From thepressure tank D the gas which still retains the heat dueto compression, passes through pipe e into the bottomor lower pipe of the condenser r, wherein, by the coolingaction of cold water running over the pipes, the heatedgas is first cooled and then liquefied. The ammonia,… … Fig. 364complete installation of a de la vergne refrigerating plant 876 - Steam Engineering part of the separating tank k^ which latter must be con-stantly maintained at the very least three-qnarters full.L is a pipe of small bore, through which the liquid am-monia is forced, by reason of the…
