Twentieth century handbook for steam engineers and electricians, with questions and answers; a practical nontechnical treatise on the care and management of steam engines, boilers and electric machinery (1922)

Swingle, Calvin Franklin, 1846- [from old catalog] · Chicago, F. J. Drake & company · leaf 1013

An illustration from Twentieth century handbook for steam engineers and electricians, with questions and answers; a practical nontechnical treatise on the care and management of steam engines, boilers and electric machinery, 1922, leaf 1013
latter being pivoted at G.The part B, which holds the pivot G is actuated by thelever K. The supply pipe is connected with the right-handend of the pilot-valve chamber through the pipe E. If therod C is moved to the. left, high-pressure water will passthrough the pilot valve to the end I of the… … Fig. 407 main valve will carry the lower end of the lever T) to theleft and the upper end to the right, until the pilot valveis returned to the closed position. If the pilot-valve rodC is moved to the right, the end I of the main valvewill be connected with the discharge and the water willescape,…

Steam engineering · Electrical engineering · Steam-turbines
