Twentieth century handbook for steam engineers and electricians, with questions and answers; a practical nontechnical treatise on the care and management of steam engines, boilers and electric machinery (1922)

Swingle, Calvin Franklin, 1846- [from old catalog] · Chicago, F. J. Drake & company · leaf 1140

An illustration from Twentieth century handbook for steam engineers and electricians, with questions and answers; a practical nontechnical treatise on the care and management of steam engines, boilers and electric machinery, 1922, leaf 1140
or should be about 3/16 in.If it is less than this, shut down the machine and movethe commutator forward or in the direction of rotation Operation of Dynamos 1105 until the spark is of the desired length. If the spark istoo long^ move the commutator back the proper amount. A general view of the… … tion is on the left-hand side, as shown in Fig. 482. Onthe left-hand machine, i. e., one which runs clockwise, itsposition is on the opposite side. Before filling the dashpot D with glycerine, see that the regulator lever and itsconnections, brush yokes, etc., are free in every joint, andthat the…

Steam engineering · Electrical engineering · Steam-turbines

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
