Twentieth century handbook for steam engineers and electricians, with questions and answers; a practical nontechnical treatise on the care and management of steam engines, boilers and electric machinery (1922)

Swingle, Calvin Franklin, 1846- [from old catalog] · Chicago, F. J. Drake & company · leaf 117

An illustration from Twentieth century handbook for steam engineers and electricians, with questions and answers; a practical nontechnical treatise on the care and management of steam engines, boilers and electric machinery, 1922, leaf 117
ned brace thepull on these rivets is direct, and the tensile strength of thematerial needs to be considered only, but if the form of thebrace is-such as to bring the rivet holes above or below thecenter line of the brace, or if the rivets are pitched too farfrom the body of the brace, there will be…

Steam engineering · Electrical engineering · Steam-turbines
