Twentieth century handbook for steam engineers and electricians, with questions and answers; a practical nontechnical treatise on the care and management of steam engines, boilers and electric machinery (1922)

Swingle, Calvin Franklin, 1846- [from old catalog] · Chicago, F. J. Drake & company · leaf 421

An illustration from Twentieth century handbook for steam engineers and electricians, with questions and answers; a practical nontechnical treatise on the care and management of steam engines, boilers and electric machinery, 1922, leaf 421
the opposite end picks up forlead. When the knock-off cams are in the position repre-sented by the lines H and H, Fig. 145, the cut-off willoccur at about three-eights of the stroke, and when theknock-off pin center is at b the valves will remain lapped,being dropped before they can open. If the… … Fig. 145 In Fig. 146 the valve-cranks are in their extreme posi-tions, and the eccentrics likewise, with everything ready tostart in the direction of the arrows. On the crank end thesteam valve is lapped, and the exhaust valve is open, while Valves and Valve Setting 409

Steam engineering · Electrical engineering · Steam-turbines

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
