een them. (The 686 Steum Engineering Bectional view is from another installation and only showsfour tubes.) Baffle plates^ C^ are arranged above the spacebetween each pair of tubes. The spaces surrounding theconduits^ and^ under certain conditions^ even the conduitsthemselves, are filled with water… … Fig. 295 the water, with, occasionally, a further escape from thebottom openings. A large baffle plate in the upper steam<«pace serves for a perfect separation of entrained moisturefrom the steam. The steam enters by the pipe shown at theleft hand of the side elevation, passes to the interior of…
