FIGURE 115. side to side to cover the entire length of the grate.The coal is shoveled or fed by carrier into thecoal magazines, one on each side, as shown in thecut If the furnace is placed directly under the boilerit necessitates putting these coal magazines within theside walls, but as the Murphy… … plate, against which the upper ends of the inclinedgrates rest. On the central part of this plate is aninverted open box. This is termed the stoker box, MECHANICAL STOKERS 343 and it is moved back and forth across the face of thecoking plate by means of a shaft with pinions thatmesh into racks…
