Twentieth century hand-book for steam engineers and electricians, with questions and answers .. (1905)

Swingle, C. F. [from old catalog], Horstmann, Henry Charles, 1858- [from old catalog], Tousley, Victor Hugo, 1875- [from old catalog] · Chicago, F. J. Drake & co. · leaf 529

An illustration from Twentieth century hand-book for steam engineers and electricians, with questions and answers .., 1905, leaf 529
motor should keep a nearly uniform speed, for varying loads, the resistance of its armature should be very low, for then a slight drop in counter E. M. F no ELECTRICITY FOR ENGINEERS will allow considerable current to flow through thearmature. The above applies particularly to the shuntmotor shown… … figure 63. over against it, F the fields, and A the armature of themotor. The current enters, say at the right hand fuse, andpasses to the starting box and along the fine wiresshown in dotted lines through the fields of the motorand coil M to the other fuse. The fields of the motorand the little…

Steam engineering · Electrical engineering · Steam turbines

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
