Skinner, Frank W. (Frank Woodward), 1858-1932 · New York, McGraw · leaf 145
Abutment and Column Bearing, FernHollow Highway Bridge. 128 BRIDGE CONSTRUCTION … ^WsdePI. I j liSpur Enlarged De+ail at A. Lofferal ConnecHon. of the substructure. The bolt holes are round and slottedthrough the sole plates at the fixed and expansion ends, re-spectively. At the expansion end, the bed sole plate has acenter guide rib engaging a slot planed in the bed plate. Fcru…
Bridges
Internet Archive · Boston Library Consortium · Public Domain Mark 1.0. Free to use for anything.
